Grandstream HT801 V2 1-Port Analog Telephone Adapter
Quick Overview
- Type: Analog Telephone Adapter (ATA)
- SIP Profile: 1 SIP Profile
- Telephone Interface: 1 FXS Port
- Network Interface: 1 × 10/100Mbps Ethernet Port
- Audio Conferencing: 3-Way Voice Conferencing
- Fax Over IP: T.38 Support
- LED Indicators: POWER, NET, PHONE
- Security: TLS and SRTP Encryption
Description
The Grandstream HT801 V2 is a compact single-port Analog Telephone Adapter (ATA) designed to provide a high-quality and manageable IP telephony solution for residential and office environments. It allows users to connect analog phones to VoIP networks while providing advanced voice functionality, security features, and automated provisioning options.
The HT801 V2 supports 1 SIP profile through a single FXS port and a 10/100Mbps Ethernet port. It also provides 3-way voice conferencing, T.38 Fax-over-IP support, failover SIP server functionality, and a wide range of caller ID formats.
For deployment and management, the device supports automated provisioning through TR-069 and XML configuration files and can be used with Grandstream’s UCM series IP PBXs for Zero Configuration provisioning.
Key Features
- Single FXS Port for Analog Telephone
- Supports One SIP Profile
- 10/100Mbps Auto-Sensing Ethernet Port
- Supports 3-Way Voice Conferencing
- T.38 Fax-over-IP Support
- TLS and SRTP Security Encryption
- Automated TR-069 Provisioning Support
- XML Configuration File Provisioning
- Failover SIP Server Support
- Supports Grandstream UCM Zero Configuration
- Advanced Telephony and Caller ID Features
- Compact Design for Office Deployments
Advanced Telephony Features
The HT801 V2 supports a range of telephony functions, including Caller ID display or blocking, call waiting, flash, blind or attended transfer, call forwarding, hold, Do Not Disturb, and 3-way conferencing.
It supports multiple voice codecs along with a dynamic jitter buffer and advanced line echo cancellation to support IP voice applications.
Fax Over IP
The HT801 V2 supports T.38-compliant Group 3 Fax Relay up to 14.4kbps and can automatically switch to G.711 for Fax Pass-through.
Security & Management
For secure communication and device management, the HT801 V2 supports SRTP for media security and TLS/SIPS/HTTPS for control. It also provides SSH, Syslog, remote web browser management, and secure automated provisioning using AES encryption.
Grandstream HT801 V2 Price in Bangladesh
For the latest Grandstream HT801 V2 price in Bangladesh, availability, warranty, and product details, contact Ellipse Technologies Ltd. Pricing and availability may vary depending on current stock and supply.
Specifications
| Specification | Details |
|---|---|
| Model | Grandstream HT801 V2 |
| Type | Analog Telephone Adapter |
| Lines | 1 Line |
| Telephone Interface | One (1) FXS Port |
| SIP Profile | 1 |
| Network Interface | One (1) 10/100Mbps Auto-Sensing Ethernet Port (RJ45) |
| LED Indicators | POWER, NET, PHONE |
| Factory Reset Button | Yes |
| Audio Conferencing | 3-Way Voice Conferencing |
| Caller ID | Bellcore Type 1 & 2, ETSI, BT, NTT, DTMF-Based CID |
| Dial Methods | DTMF, Pulse |
| Fax Over IP | T.38 Compliant Group 3 Fax Relay up to 14.4kbps |
| Voice Codecs | G.711, G.722, G.723.1, G.729A/B, G.726-32, iLBC, Opus |
| Ring Load | 5 REN, Up to 1km on 24 AWG |
| Network Protocols | TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS, DHCP, NTP, TFTP, SSH, Telnet, STUN, SIP, SRTP, SNMP, TR-069, IMS/3GPP, IPoE |
| QoS | Layer 2 and Layer 3 |
| DTMF Method | In-audio, RFC2833 and/or SIP INFO |
| Provisioning & Control | HTTP, HTTPS, SSH, TFTP, TR-069, AES Encryption, Syslog |
| Media Security | SRTP |
| Control Security | TLS/SIPS/HTTPS |
| Management | Syslog, SSH, Remote Web Browser Management |
| Power Input | 100–240VAC, 50–60Hz |
| Power Output | 5.0VDC / 1.0A |
| Operating Temperature | 0°C – 40°C |
| Storage Temperature | -10°C – 60°C |
| Humidity | 10–90% Non-Condensing |
| Dimensions | 100 × 100 × 29.5 mm |
| Weight | 102 g |
| Compliance | FCC Part15B, CE, RCM |
The specifications above are based on the uploaded Grandstream HT801 V2, including its interface, telephony, codec, fax, networking, security, power, environmental, and physical specifications.
