Grandstream GCC6010 IPPBX, Firewall, Router and Switch
Key Features
- Unified Communication and Networking Solution
- Integrated Router, Firewall, VPN and IP PBX
- Secure Network Management and Connectivity
- Advanced UC and Collaboration Features
- Centralized Management for Business Networks
Specifications
General
| Specification | Details |
|---|---|
| Brand | Grandstream |
| Model | GCC6010 |
| Type | UC + Networking Convergence Solution |
| Architecture | All-in-One UC, Networking & Security Platform |
| CPU | Quad-Core CA53, 2.0 GHz |
| RAM | 2 GB |
| Internal Storage | 32 GB eMMC Flash |
| Material | Metal |
| Mounting | Desktop / Wall Mount |
| Connection Type | DHCP, Static IP, PPPoE |
The GCC6010 combines the functionality of a VPN router, next-generation firewall, IP PBX and network switch into one centralized platform.
Network Interfaces
| Specification | Details |
|---|---|
| SFP+ Ports | 2 × 2.5G SFP+ |
| Gigabit Ethernet Ports | 5 × Gigabit Ethernet |
| WAN/LAN Configuration | All ports configurable |
| Maximum WAN Ports | Up to 3 WAN ports |
| PoE Ports | 4 × PoE |
| PoE Standard | IEEE 802.3af/at |
| Maximum PoE Power | 36 W |
| Routing Speed | Up to 2.5 Gbps |
| NAT Sessions | Up to 160K |
VPN
| Specification | Details |
|---|---|
| IPsec VPN Throughput | Up to 1 Gbps |
| IPsec VPN | Client-to-Site / Site-to-Site |
| OpenVPN | Server / Client |
| PPTP | Server / Client |
| L2TP | Client-to-Site |
| WireGuard | Supported |
| IPsec Encryption | 3DES, AES |
| IPsec Authentication | MD5, SHA-1, SHA2-256 |
| IPsec NAT Traversal | Supported |
| Remote Access | Secure remote access and site-to-site connectivity |
The platform supports multiple VPN technologies including WireGuard, OpenVPN, PPTP, L2TP and IPsec.
Firewall & Security
| Feature | Details |
|---|---|
| Firewall | Enterprise-grade firewall |
| Stateful Inspection | Supported |
| DoS Protection | UDP / ICMP / SYN Flood Protection |
| Spoofing Defense | Enhanced spoofing protection |
| IDS/IPS | Up to 900 Mbps |
| DPI | Deep Packet Inspection |
| SSL Inspection | Real-time SSL Deep Inspection |
| Anti-Virus | Supported |
| SSL Proxy | Supported |
| DNS Filtering | Supported |
| Web Filtering | URL, category & keyword filtering |
| Application Control | Application identification and control |
| GeoIP Enforcement | Supported |
| Traffic Filtering | Source, destination, protocol and port |
Routing & Multi-WAN
- Dynamic routing
- Multi-WAN capabilities
- WAN load balancing
- WAN link failover
- Performance-based WAN link selection
- WAN monitoring
- NAT
- VLAN support
- DHCP Server
- DNS Server
- IGMP Proxy
- TURN Server
- IPv4 / IPv6 support
Quality of Service (QoS)
- VLAN and ToS support
- Multiple traffic classes
- Port-based traffic filtering
- IP-based traffic filtering
- DSCP filtering and policing
- Application-level QoS
- VoIP prioritization
IP PBX
| Specification | Details |
|---|---|
| PBX Users | 24 users by default |
| Concurrent Calls | 8 concurrent calls by default |
| Capacity Upgrade | Available for purchase |
| PBX Services | Call Forwarding, Transfer, Parking, Intercom/Paging, IVR, Emergency Calls & more |
| Conferencing | Built-in Audio & Video Conferencing |
| Wave Support | Desktop / Web / Android / iOS |
| SIP Endpoint Provisioning | Fast provisioning |
| API | Full API for third-party integration |
| CRM Integration | Supported |
| Call Center Integration | Supported |
| PMS Integration | Supported |
Audio & Video Codec Support
Audio Codecs:
- Opus
- G.711 A-law/U-law
- G.722
- G.722.1
- G.722.1C
- G.723.1
- G.726-32
- G.729A/B
- iLBC
- GSM
- T.38
Video Codecs:
- H.264
- H.263
- H.263+
- VP8
Voice/Media Optimization:
- FEC
- Jitter Buffer
- NetEQ
- ToS
- DSCP
- Jitter resilience
Management
| Management Method | Support |
|---|---|
| Grandstream Device Management System (GDMS) | Yes |
| Local Web GUI | Yes |
| SSH | Yes |
| SNMP | v1 / v2c / v3 |
| Centralized Management | Yes |
| Visual Network Topology | Yes |
| Mass Provisioning | Supported |
| Grandstream Endpoint Integration | Supported |
The GCC6010 can centrally manage Grandstream Wi-Fi access points, switches and UC endpoints, with quick provisioning for large deployments.
Auxiliary Interfaces
| Interface | Details |
|---|---|
| Micro-SD | 1 × |
| USB | 1 × USB 3.0 |
| Reset Button | 1 × |
Network Protocols
- IPv4
- IPv6
- IEEE 802.1Q
- IEEE 802.1p
- IEEE 802.1x
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3ab
Power
- Power Adapter: Universal Power Adapter
- Input: 100–240V AC, 50–60Hz
- Output: 12V DC, 1.5A
- Power: 18W
Environmental
| Specification | Details |
|---|---|
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -30°C to 60°C |
| Storage Humidity | 5%–95%, Non-Condensing |
Physical
| Specification | Details |
|---|---|
| Dimensions | 95 × 95 × 193 mm |
| Weight | 565 g |
| Material | Metal |
| Mounting | Desktop / Wall Mount |
Key Features
1. All-in-One Convergence Platform
Combines a VPN router, next-generation firewall, IP PBX and network switch into one solution, reducing the need for multiple standalone devices.
2. High-Speed Networking
Provides 2 × 2.5G SFP+ ports and 5 × Gigabit Ethernet ports, with flexible WAN/LAN configuration and support for up to three WAN connections.
3. Advanced Multi-WAN
Supports WAN load balancing, failover and performance-based WAN link selection to improve network reliability.
4. Enterprise-Grade Firewall
Provides stateful packet inspection, DoS protection, spoofing defense, IDS/IPS, DPI, SSL inspection and application control.
5. Multiple VPN Technologies
Supports IPsec, OpenVPN, WireGuard, PPTP and L2TP for secure remote-access and site-to-site connectivity.
6. Integrated IP PBX
Includes built-in IP PBX functionality supporting 24 users and 8 concurrent calls by default, with paid capacity upgrades available.
7. Built-in Collaboration
Supports integrated audio/video conferencing through Wave Desktop, Web, Android and iOS platforms.
8. Advanced QoS
Provides application QoS, traffic classification, DSCP filtering and dedicated VoIP prioritization for communication traffic.
9. Centralized Management
Manage Grandstream networking and communication endpoints through GDMS, Web GUI, SSH and SNMP from a centralized platform.
10. PoE Support
Four PoE ports support IEEE 802.3af/at with a maximum total PoE output of 36W.
Benefits
Simplified IT Infrastructure
Consolidating networking, security and communication functions into one device can reduce hardware complexity, installation requirements and management overhead.
Reduced Deployment Complexity
A single platform can handle core networking, firewall, VPN and IP PBX requirements, making deployment easier for offices and branch locations.
Improved Network Reliability
Multi-WAN load balancing and automatic failover help maintain connectivity when a WAN connection becomes unavailable.
Enhanced Network Security
Integrated firewall, IDS/IPS, DPI, anti-virus, SSL inspection and threat-protection capabilities provide multiple layers of network protection.
Secure Remote Connectivity
Multiple VPN technologies enable secure connections between offices, remote users and private networks.
Better VoIP Performance
Advanced QoS and VoIP prioritization help prioritize voice traffic and maintain communication quality during network congestion.
Centralized Administration
IT teams can monitor and manage compatible Grandstream endpoints from a centralized management environment, including network topology visualization and quick provisioning.
Scalable Business Solution
The integrated platform is designed for small and medium-sized businesses and provides upgrade options for increasing IP PBX capacity as business requirements grow.
Why Choose Grandstream GCC6010?
The Grandstream GCC6010 is designed for organizations that want to combine networking, security and unified communications into a single manageable platform. Its integrated VPN router, enterprise firewall, IP PBX, switching, QoS and centralized management capabilities make it suitable for modern business infrastructure where simplicity, security and scalability are important.
Recommended for: Offices, SMEs, branch offices, retail businesses, corporate networks, professional organizations and businesses requiring integrated Networking + Firewall + VPN + IP PBX functionality.
